Peanut Butter Machine

DTDC High Efficient Desolventizer-Toaster For Oil Extraction

DTDC high efficient desolventizer toaster

Features of DTDC desolventizer-toaster:
DTDC desolventizer-toaster is the best equipment for desolventizing the extracted wet meal to realize its desolvation and drying. It can be used to cool the extracted meal with the temperature of 5-10 ℃ higher than ambient temperature for direct packaging and storage. Four layers of indirect steam are used for heating in pre-desolvation. The evaporation layer uses direct steam and the dry layer uses hot-air. Each material layer is provided with a stirring and material level control device to achieve fully pre-desolvation, evaporation and drying effect and reduce the solvent residues effectively. The urease activity of the meal would be reduced to 0.3 mg nitrogen /g/min at around 30℃ on the condition of maintaining the activity of protein at the most extent.

The advantages of DTDC desolventizer-toaster:
1.To inactivate and destroy the anti nutrients like urease and trypsin in the meal to improve its utilization value;
2.To control the degree of protein denaturation and effectively improve the NSI index of meal;
3.To improve the color and flavor of the meal;
4.To reduce the residual solvent in the meal and regulate the moisture of the meal, so as to ensure the lowest solvent consumption and the safe use of the meal

DTDC high efficient desolventizer toaster

Characteristics of Huatai DTDC desolventizer-toaster:
1.DTDC desolventizer-toaster is the main equipment of desolventizing system of leaching plant, capable of removing the solvent in the wet meal.
2.DTDC desolventizer-toaster has perfect functions. Pre-desolvation, evaporation, drying and cooling of wet meal can be achieved. The wet meal after desolventizingy can be packaged directly;
3.With large transmission torque and load weight;
4.After complete desolventizing of the wet meal, urease activity would be remained at 0.15~0.25, which improves the quality of oil and meal.

Model Capacity(t/d) Heat exchange area M2 Height mm Power KW Weight(Mt)
DT140 30 10 6020 15 5
DT160 30~50 11 6020 18.5 6.5
DT180 50 11.5 6300 18.5 8
DT200 80 13.2 6300 22 12
DT220 100 15.5 6300 22 14
